Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 4XA5 |
| Airport Status: | Operational |
| Longitude/Latitude: | 098-29-45.6000W/34-02-15.9000N
-98.496000/34.037750 (Estimated) |
| Elevation: | 1004 ft / 306.02 m (Estimated) |
| Land: | 23 acres |
| From nearest city: | 5 nautical miles SE of Burkburnett, TX |
| Location: | Wichita County, TX |
| Magnetic Variation: | () |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | Bruce And June Shipp |
| Address: | 1233 Cashion Rd
Wichita Falls, TX 76305 |
| Phone number: | 940-636-8474 |
| Manager: | Bruce And June Shipp |
| Address: | 1233 Cashion Rd
Wichita Falls, TX 76305 |
| Phone number: | 940-636-8474 |
Airport Operations and Facilities
| Airport Use: | Private |
| Wind indicator: | Yes |
| Control Tower: | No |
| Sectional chart: | Dallas-ft Worth |
| Region: | ASW - Southwest |
| Boundary ARTCC: | ZFW - Fort Worth |
| Tie-in FSS: | FTW - Fort Worth |
| FSS Phone: | 817-541-3474 |
| FSS Toll Free: | 1-800-WX-BRIEF |
Runway Information
Runway 17/35
| Dimension: | 1849 x 50 ft / 563.6 x 15.2 m |
| Surface: | TURF, |
| |
Runway 17 |
Runway 35 |
| Traffic Pattern: | Left | Right |
| Obstruction: | 21 ft tree, 403.0 ft from runway | 27 ft pline |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| FSI | FAN MARKER | Trail | | | 09E | 44.9 nm |
| SKB | NDB | Scotland | | 344.00 | 08E | 14.9 nm |
| PFL | NDB | Post | | 308.00 | 08E | 34.6 nm |
| VRT | NDB | Wilbarger | | 230.00 | 08E | 40.6 nm |
| ONY | NDB | Olney | | 272.00 | 07E | 44.3 nm |
| GMZ | NDB | Grindstone Mountain | | 356.00 | 07E | 44.5 nm |
| OFZ | NDB | Trail | | 388.00 | 09E | 44.9 nm |
| SHP | TACAN | Sheppard | 045X | | 10E | 3.3 nm |
| LAW | VOR/DME | Lawton | 031X | 109.40 | 09E | 27.9 nm |
| DUC | VOR/DME | Duncan | 047X | 111.00 | 09E | 35.5 nm |
| SPS | VORTAC | Wichita Falls | 074X | 112.70 | 10E | 5.7 nm |
| UKW | VORTAC | Bowie | 071X | 112.40 | 06E | 45.2 nm |
Remarks
- 4-SHIPP ARPT IS LOCATED WITHIN SHEPPARD AFB'S CLASS D SURFACE AREA. A LOA IS IN EFFECT BETWEEN 4-SHIPP ARPT & 80TH FLYING TNG WING/SHEPPARD AFB. ALL OPERATIONS WILL BE ACCORDANCE WITH THIS LOA. FLIGHTS TO/FM 4-SHIPP BY NON-BASED AIRCRAFT ARE NOT PERMITTED DURING 80TH FTW OPS.
- SHEPPARD AFB ATCT WILL DENY NON-BASED AIRCRAFT ENTRY INTO SHEPPARDS CLASS D AIRPACE WHEN MILITARY FLT TNG IS IN PROGRESS AT SHEPPARD AFB.
- EXTREME CARE MUST BE EXERCISED DUE TO THE PROXIMITY OF SHEPPARD AFB AND THE HIGH-PERFORMANCE MILITARY JET TFC IN THE VICINITY OF 4- SHIPP ARPT. ALL OPERATIONS WILL BE CONDUCTED UNDER VFR AND SEE AND AVOID PROCEDURES APPLY AT ALL TIMES.
- SHEPPARD AFB ATCT WILL NOT BE RESPONSIBLE FOR AIRCRAFT SEPARATION. AIRCRAFT OPERATING TO/FROM 4-SHIPP AIRFIELD WILL REMAIN CLEAR OF AND GIVE WAY TO CIIVILIAN/MILITARY TRAFFIC OPERATING IN SHEPPARD AFB TRAFFIC PATTERNS.
- PRVDD LOA WITH SHEPPARD AFB.
