A.h. Butz Downtown Allentown Heliport |
Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 24PN |
| Airport Status: | Operational |
| Longitude/Latitude: | 075-28-30.3000W/40-36-03.8000N
-75.475083/40.601056 (Estimated) |
| Elevation: | 456 ft / 138.99 m (Estimated) |
| Land: | 0 acres |
| From nearest city: | 0 nautical miles N of Allentown, PA |
| Location: | Lehigh County, PA |
| Magnetic Variation: | () |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | A. H. Butz Inc |
| Address: | 840 Hamilton St Suite 600
Allentown, PA 18101 |
| Phone number: | 610-395-6871 |
| Manager: | John R. Forsht Iii |
| Address: | 840 Hamilton St Suite 600
Allentown, PA 18101 |
| Phone number: | 610-395-6871 |
Airport Operations and Facilities
| Airport Use: | Private |
| Wind indicator: | Yes |
| Control Tower: | No |
| Lighting Schedule: | PHONE REQ
FOR PERIMETER AND FLOOD LGTS CALL 610-395-6871. |
| Sectional chart: | New York |
| Region: | AEA - Eastern |
| Boundary ARTCC: | ZNY - New York |
| Tie-in FSS: | IPT - Williamsport |
| FSS Toll Free: | 1-800-WX-BRIEF |
Runway Information
Helipad H1
| Dimension: | 45 x 45 ft / 13.7 x 13.7 m |
| Surface: | CONC, |
| |
Runway H1 |
Runway |
| Traffic Pattern: | Left | Left |
|
Helipad H2
| Dimension: | 45 x 45 ft / 13.7 x 13.7 m |
| Surface: | CONC, |
| |
Runway H2 |
Runway |
| Traffic Pattern: | Left | Left |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| UKT | NDB | Quakertown | | 208.00 | 12W | 13.3 nm |
| LQX | NDB | Carbon | | 339.00 | 12W | 18.1 nm |
| DYL | NDB | Doylestown | | 237.00 | 10W | 22.7 nm |
| NXX | NDB | Willow Grove | | 388.00 | 12W | 29.0 nm |
| ING | NDB | Ambler | | 275.00 | 11W | 29.9 nm |
| HXM | NDB | Humbolt | | 366.00 | 10W | 33.3 nm |
| CYE | NDB | Crystal Lake | | 410.00 | 11W | 40.1 nm |
| CAT | NDB | Chatham | | 254.00 | 11W | 48.4 nm |
| NXX | TACAN | Willow Grove | 061X | | 10W | 28.7 nm |
| HZL | VOR | Hazleton | | 109.40 | 09W | 37.2 nm |
| PNE | VOR | North Philadelphia | | 112.00 | 10W | 37.8 nm |
| ETX | VOR/DME | East Texas | 039X | 110.20 | 09W | 9.6 nm |
| CKZ | VOR/DME | Pennridge | 025Y | 108.85 | 12W | 15.2 nm |
| BWZ | VOR/DME | Broadway | 089X | 114.20 | 11W | 32.0 nm |
| ARD | VOR/DME | Yardley | 019X | 108.20 | 10W | 33.3 nm |
| SBJ | VOR/DME | Solberg | 076X | 112.90 | 10W | 33.5 nm |
| STW | VOR/DME | Stillwater | 033X | 109.60 | 11W | 36.4 nm |
| FJC | VORTAC | Allentown | 122X | 117.50 | 10W | 7.6 nm |
| PTW | VORTAC | Pottstown | 112X | 116.50 | 09W | 23.1 nm |
| LVZ | VORTAC | Wilkes-barre | 053X | 111.60 | 10W | 41.5 nm |
| MXE | VORTAC | Modena | 079X | 113.20 | 09W | 42.0 nm |
| LRP | VORTAC | Lancaster | 120X | 117.30 | 09W | 47.3 nm |
| PHL | VOT | Philadelphia Intl | | 109.80 | | 45.2 nm |
Remarks
- MAX ROTOR DIAMETER IS 45 FT.
- MAX GROSS WEIGHT IS 15,000 LBS.
- WRITTEN PERMISSION REQD PRIOR TO USING THESE HELIPADS.
- EMERG SVC HEL CTC MGR 610-396-6871 FOR DETAILS.
- USE PRIM APCH/DEP PATHS OF 060/240 DEGS FOR NOISE ABATEMENT AND GOOD COMMUNITY RELATIONS. IF THERE IS AN ISSUE OF SAFETY OR CRITICAL EMERG MISSION NEED; OTHER PATHS MAYBE USED IF NEEDED.
- THE PERIMETER SAFETY FENCE AND LIGHTS ARE SLIGHTLY HIGHER THAN THE PAD; EXERCISE CARE DURING MANUVERING TO, FM AND ON THE PAD.
