Speedway Northside Heliport |
Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 2NH6 |
| Airport Status: | Operational |
| Longitude/Latitude: | 071-27-21.0000W/43-21-57.0000N
-71.455833/43.365833 (Estimated) |
| Elevation: | 560 ft / 170.69 m (Estimated) |
| Land: | 0 acres |
| From nearest city: | 5 nautical miles N of Loudon, NH |
| Location: | Merrimack County, NH |
| Magnetic Variation: | () |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | Nh Intl Speedway
ROBERT BAHRE. |
| Address: | Po Box 7888
Loudon, NH 03307 |
| Phone number: | 603-783-4744 |
| Manager: | Ray Newecomb |
| Address: | 720 Clough Mill Rd
Pembroke, NH 03275 |
| Phone number: | 603-225-3134 |
Airport Operations and Facilities
| Airport Use: | Private |
| Wind indicator: | Yes |
| Control Tower: | No |
| Lighting Schedule: | RDO-CTL
ACTVT PERIMETER LGTS - 123.05. |
| Sectional chart: | New York |
| Region: | ANE - New England |
| Boundary ARTCC: | ZBW - Boston |
| Tie-in FSS: | BGR - Bangor |
| FSS Toll Free: | 1-800-WX-BRIEF |
Runway Information
Helipad H1
| Dimension: | 35 x 35 ft / 10.7 x 10.7 m |
| Surface: | CONC, |
| |
Runway H1 |
Runway |
| Traffic Pattern: | Left | Left |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| LCI | FAN MARKER | Laconia | | | | 12.1 nm |
| SZO | FAN MARKER | Grinn | | | 17W | 43.4 nm |
| LC | NDB | Blnap | | 328.00 | 16W | 10.9 nm |
| CO | NDB | Epsom | | 216.00 | 16W | 14.9 nm |
| ESG | NDB | Rollins | | 260.00 | 16W | 28.8 nm |
| DRY | NDB | Derry | | 338.00 | 16W | 29.9 nm |
| AS | NDB | Chern | | 359.00 | 16W | 33.2 nm |
| LAH | NDB | Hanover | | 276.00 | 15W | 37.4 nm |
| CNH | NDB | Claremont | | 233.00 | 16W | 40.0 nm |
| SZO | NDB | Sebago | | 227.00 | 17W | 43.7 nm |
| IVV | NDB | White River | | 379.00 | 16W | 45.6 nm |
| SXD | NDB | Springfield | | 265.00 | 15W | 49.8 nm |
| TOF | NDB | Topsfield | | 269.00 | 16W | 49.9 nm |
| MHT | VOR/DME | Manchester | 091X | 114.40 | 15W | 30.1 nm |
| PSM | VOR/DME | Pease | 112X | 116.50 | 16W | 32.1 nm |
| LEB | VOR/DME | Lebanon | 084X | 113.70 | 15W | 38.1 nm |
| LWM | VOR/DME | Lawrence | 072X | 112.50 | 15W | 40.8 nm |
| CON | VORTAC | Concord | 076X | 112.90 | 15W | 10.2 nm |
| ENE | VORTAC | Kennebunk | 118X | 117.10 | 17W | 37.0 nm |
Remarks
- HELIPAD INCLUDES SEVERAL PARKING PADS.
- PRVDD VFR OPNS PVT USE; SMALL AND MEDIUM SIZE HELOS ONLY; REMOVE 30 FT TREES S & W OF PAD; EGRESS 280-330 DEGREES OR SECONDARY 300-030 DEGREES AND 120-140 DEGREES; & INGREE 280-330 DEGREES & 100-120 DEGREES OR SECONDARY 120-140 DEGREES.
