Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | MYJ |
| Airport Status: | Operational |
| Longitude/Latitude: | 091-49-05.7600W/39-09-27.0500N
-91.818267/39.157514 (Estimated) |
| Elevation: | 823 ft / 250.85 m (Surveyed) |
| Land: | 290 acres |
| From nearest city: | 3 nautical miles E of Mexico, MO |
| Location: | Audrain County, MO |
| Magnetic Variation: | 02E (2000) |
Owner & Manager
| Ownership: | Publicly owned |
| Owner: | City Of Mexico |
| Address: | 800 N. Coal
Mexico, MO 65265 |
| Phone number: | 573-581-2100 |
| Manager: | Jay Jacobi |
| Address: | 5720 Hwy 54 East
Mexico, MO 65265 |
| Phone number: | 573-581-0162 |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | Yes |
| Control Tower: | No |
| Lighting Schedule: | DUSK-DAWN
MIRL RY 06/24 & LIRL RY 18/36 PRESENT ON LOW INTST DUSK-2000; AFTER 2000 ACTVT LIRL RY 18/36, MIRL RY 06/24, PAPI RY 24, MALS RY 24, AND REIL RY 18 - CTAF. |
| Beacon Color: | Clear-Green (lighted land airport) |
| Landing fee charge: | No |
| Sectional chart: | Kansas City |
| Region: | ACE - Central |
| Boundary ARTCC: | ZKC - Kansas City |
| Tie-in FSS: | STL - Saint Louis |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | STL (NOTAM-d service avaliable) |
| Federal Agreements: | NGY |
Airport Communications
Airport Services
| Fuel available: | 100LLA MOGAS
24 HR CREDIT CARD FUEL SYSTEM. FOR JET A FUEL AFTER HRS CALL AIRPORT MGR 573-473-7758. |
| Airframe Repair: | MAJOR |
| Power Plant Repair: | MAJOR |
| Bottled Oxygen: | NONE |
| Bulk Oxygen: | NONE |
Runway Information
Runway 06/24
| Dimension: | 5501 x 100 ft / 1676.7 x 30.5 m |
| Surface: | CONC, Good Condition |
| Weight Limit: | Single wheel: 30000 lbs.
Dual wheel: 37000 lbs. |
| Edge Lights: | Medium
NSTD LIRL--THR LGTS SPACED TOO CLOSE. |
| |
Runway 06 |
Runway 24 |
| Longitude: | 091-49-31.9189W | 091-48-28.2771W |
| Latitude: | 39-09-15.4476N | 39-09-37.8317N |
| Elevation: | 823.00 ft | 809.00 ft |
| Alignment: | 66 | 127 |
| ILS Type: | | LOC/DME
|
| Traffic Pattern: | Left | Left |
| Markings: | Non-precision instrument, Good Condition | Non-precision instrument, Good Condition |
| Crossing Height: | 0.00 ft | 40.00 ft |
| Displaced threshold: | 0.00 ft | 371.00 ft |
| VASI: | | 4-light PAPI on left side |
| Visual Glide Angle: | 0.00° | 3.00° |
| Approach lights: | | MALS |
| Obstruction: | 33 ft pole, 1240.0 ft from runway, 345 ft left of centerline, 31:1 slope to clear | 75 ft ant, 2400.0 ft from runway, 120 ft left of centerline, 29:1 slope to clear
RWY 24 36:1 BASED ON DSPLCD THLD. |
|
Runway 18/36
| Dimension: | 3199 x 50 ft / 975.1 x 15.2 m |
| Surface: | ASPH-CONC, Good Condition |
| Weight Limit: | Single wheel: 10000 lbs. |
| Edge Lights: | Non-standard lighting system
NSTD LIRL--THR LGTS SPACED TOO CLOSE. |
| |
Runway 18 |
Runway 36 |
| Longitude: | 091-49-14.8992W | 091-49-16.0687W |
| Latitude: | 39-09-43.5394N | 39-09-11.9283N |
| Elevation: | 812.00 ft | 818.00 ft |
| Alignment: | 127 | 2 |
| Traffic Pattern: | Left | Left |
| Markings: | Basic, Good Condition | Basic, Good Condition |
| Runway End Identifier: | Yes | |
| Obstruction: | 30 ft pole, 1045.0 ft from runway, 190 ft right of centerline, 28:1 slope to clear | 34 ft tree, 1150.0 ft from runway, 161 ft left of centerline, 27:1 slope to clear |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| FTT | NDB | Guthrie | | 317.00 | 03E | 20.8 nm |
| ONH | NDB | Noah | | 515.00 | 03E | 37.1 nm |
| HAE | NDB | Hannibal | | 411.00 | 03E | 38.3 nm |
| JE | NDB | Algoa | | 397.00 | 03E | 38.5 nm |
| VER | NDB | Viertel | | 347.00 | 02E | 42.3 nm |
| COU | VOR/DME | Columbia | 039X | 110.20 | 03E | 28.0 nm |
| MCM | VOR/DME | Macon | 076X | 112.90 | 06E | 42.9 nm |
| HLV | VORTAC | Hallsville | 089X | 114.20 | 06E | 14.7 nm |
| FTZ | VORTAC | Foristell | 045X | 110.80 | 05E | 48.4 nm |
| UIN | VORTAC | Quincy | 083X | 113.60 | 05E | 48.5 nm |
| JEF | VOT | Jefferson City | | 112.00 | | 37.5 nm |
Remarks
- CROP DUSTING ACFT ON & INVOF ARPT.
