Mexico Farms Airport

Mexico Farms Airport
IATA: none – ICAO: none – FAA LID: 1W3
Summary
Airport type		Public
Location		Cumberland, MD
Elevation AMSL		607 ft / 185 m
Coordinates		39°36′17″N 078°45′38″W / 39.60472°N 78.76056°W / 39.60472; -78.76056Coordinates: 39°36′17″N 078°45′38″W / 39.60472°N 78.76056°W / 39.60472; -78.76056
Runways
Direction	Length		Surface
Direction	ft	m	Surface
9/27	2,120	646	Sod
16/34	2,100	640	Turf

Mexico Farms Airport (FAA LID: 1W3) is a public airport located 3 miles (4.8 km) south of downtown Cumberland, Maryland, United States. The airport is located immediately south of the larger Greater Cumberland Regional Airport.

Resources for this airport:
- AirNav airport information for 1W3
- FlightAware airport information and live flight tracker
- SkyVector aeronautical chart for 1W3

The above content comes from Wikipedia and is published under free licenses – click here to read more.

Mexico Farms Airport picture

Location & QuickFacts

FAA Information Effective:	2008-09-25
Airport Identifier:	1W3
Airport Status:	Operational
Longitude/Latitude:	078-45-39.2000W/39-36-18.9000N -78.760889/39.605250 (Estimated)
Elevation:	607 ft / 185.01 m (Estimated)
Land:	50 acres
From nearest city:	3 nautical miles S of Cumberland, MD
Location:	Allegany County, MD
Magnetic Variation:	08W (1985)

Owner & Manager

Ownership:	Privately owned
Owner:	Mrs. Mary Ellen Johnson
Address:	14112 Airport Ln, Se Cumberland, MD 21502
Phone number:	301-724-3045
Manager:	Mr. Donald Johnson Jr.
Address:	11107 Mexico Farms Cumberland, MD 21502
Phone number:	301-724-5231

Airport Operations and Facilities

Airport Use:	Open to public
Wind indicator:	Yes
Segmented Circle:	No
Control Tower:	No
Lighting Schedule:	RDO-CTL ACTVT LIRL RY 09/27 & APAP RY 27 - 122.7.
Landing fee charge:	No
Sectional chart:	Washington
Region:	AEA - Eastern
Traffic Pattern Alt:	800 ft
Boundary ARTCC:	ZOB - Cleveland
Tie-in FSS:	EKN - Elkins
FSS on Airport:	No
FSS Toll Free:	1-800-WX-BRIEF
NOTAMs Facility:	EKN (NOTAM-d service avaliable)

Airport Communications

CTAF:	122.800
Unicom:	122.800 122.8 SHARED WITH CUMBERLAND MUNICIPAL 1/2 MI DUE NORTH.

Airport Services

Airframe Repair:	NONE
Power Plant Repair:	NONE
Bottled Oxygen:	NONE
Bulk Oxygen:	NONE

Runway Information

Runway 09/27

Dimension:

2120 x 190 ft / 646.2 x 57.9 m

Surface:

TURF, Good Condition

Edge Lights:

Low

	Runway 09	Runway 27
Longitude:	078-45-51.0100W	078-45-24.0100W
Latitude:	39-36-20.5800N	39-36-22.3000N
Traffic Pattern:	Right	Left
Crossing Height:	0.00 ft	33.00 ft
VASI:		system of panels on left side that may or may not be lighted
Visual Glide Angle:	0.00°	5.50°
Obstruction:	70 ft trees, 2000.0 ft from runway, 28:1 slope to clear	40 ft trees, 855.0 ft from runway, 60 ft right of centerline, 20:1 slope to clear

Runway 16/34

Dimension:

2100 x 195 ft / 640.1 x 59.4 m

Surface:

TURF, Good Condition

	Runway 16	Runway 34
Longitude:	078-45-47.3300W	078-45-34.3200W
Latitude:	39-36-25.3200N	39-36-07.1600N
Traffic Pattern:	Left	Left
Displaced threshold:	0.00 ft	800.00 ft
Obstruction:	20 ft brush, 10.0 ft from runway, 110 ft right of centerline	50 ft tree, 25.0 ft from runway APCH SLOPE 16:1 TO DSPLCD THLD.

Radio Navigation Aids

ID	Type	Name	Ch	Freq	Var	Dist
CBE	NDB	Cumberland		317.00	07W	2.7 nm
SYS	NDB	Stoystown		209.00	08W	29.8 nm
TZ	NDB	Cogan		364.00	10W	44.8 nm
VV	NDB	Camor		299.00	08W	48.4 nm
HGR	VOR	Hagerstown		109.80	07W	42.3 nm
AOO	VOR	Altoona		108.80	07W	48.1 nm
GRV	VOR/DME	Grantsville	070X	112.30	06W	13.5 nm
ESL	VOR/DME	Kessel	045X	110.80	06W	25.2 nm
IHD	VORTAC	Indian Head	019X	108.20	06W	35.4 nm
THS	VORTAC	St Thomas	097X	115.00	07W	42.3 nm
JST	VORTAC	Johnstown	077X	113.00	06W	42.9 nm
MRB	VORTAC	Martinsburg	058X	112.10	07W	44.3 nm

Remarks

ULTRALIGHT ACTIVITY ON & INVOF ARPT.
RISING TERRAIN 4500 FT WEST OF ARPT.
RYS 09/27 & 16/34 MAY BE SOFT.
WILDLIFE ON & INVOF ARPT.
ESTAB PRIOR 1959

Images and information placed above are from
http://www.airport-data.com/airport/1W3/

We thank them for the data!

General Info
Country United States
State MARYLAND
FAA ID 1W3
Latitude 39-36-17.319N
Longitude 078-45-38.065W
Elevation 607 feet
Near City CUMBERLAND
