Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 1MD8 |
| Airport Status: | Operational |
| Longitude/Latitude: | 077-05-49.9370W/39-40-58.3590N
-77.097205/39.682877 (Estimated) |
| Elevation: | 580 ft / 176.78 m (Estimated) |
| Land: | 4 acres |
| From nearest city: | 3 nautical miles W of Westminster/silver Run, MD |
| Location: | Carroll County, MD |
| Magnetic Variation: | 10W (1985) |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | John Million |
| Address: | 2600 E. Mayberry Rd
Westminster, MD 21157 |
| Phone number: | 410-346-7700 |
| Manager: | John Million |
| Address: | 2600 E. Mayberry Rd
Westminster, MD 21157 |
| Phone number: | 410-346-7700 |
Airport Operations and Facilities
| Airport Use: | Private |
| Wind indicator: | Yes |
| Segmented Circle: | No |
| Control Tower: | No |
| Landing fee charge: | No |
| Sectional chart: | Washington |
| Region: | AEA - Eastern |
| Boundary ARTCC: | ZNY - New York |
| Responsible ARTCC: | ZDC - Washington |
| Tie-in FSS: | DCA - Leesburg |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
Runway Information
Runway 06/24
| Dimension: | 1900 x 100 ft / 579.1 x 30.5 m
200' OVER RUN END RWY 06. |
| Surface: | TURF, |
| |
Runway 06 |
Runway 24 |
| Traffic Pattern: | Left | Left |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| EUD | NDB | York | | 254.00 | 11W | 17.5 nm |
| FND | NDB | Ellicott | | 371.00 | 11W | 28.0 nm |
| GAI | NDB | Gaithersburg | | 385.00 | 09W | 31.0 nm |
| IUB | NDB | Institute | | 404.00 | 08W | 32.3 nm |
| BUH | NDB | Anne Arundel | | 260.00 | 10W | 39.3 nm |
| MTN | NDB | Martin | | 342.00 | 11W | 40.5 nm |
| GTN | NDB | Georgetown | | 323.00 | 09W | 45.3 nm |
| APG | NDB | Aberdeen | | 349.00 | 11W | 46.7 nm |
| MTN | TACAN | Martin | 068X | | 11W | 38.2 nm |
| FDK | VOR | Frederick | | 109.00 | 08W | 20.8 nm |
| HGR | VOR | Hagerstown | | 109.80 | 07W | 35.1 nm |
| PPM | VOR/DME | Phillips | 021X | 108.40 | 09W | 44.8 nm |
| DCA | VOR/DME | Washington | 047X | 111.00 | 09W | 49.6 nm |
| EMI | VORTAC | Westminster | 126X | 117.90 | 08W | 12.6 nm |
| BAL | VORTAC | Baltimore | 098X | 115.10 | 11W | 36.8 nm |
| HAR | VORTAC | Harrisburg | 072X | 112.50 | 10W | 37.3 nm |
| MRB | VORTAC | Martinsburg | 058X | 112.10 | 07W | 39.1 nm |
| THS | VORTAC | St Thomas | 097X | 115.00 | 07W | 42.2 nm |
| LRP | VORTAC | Lancaster | 120X | 117.30 | 09W | 45.5 nm |
| AML | VORTAC | Armel | 082X | 113.50 | 08W | 48.1 nm |
| MDT | VOT | Harrisburg International | | 110.00 | | 34.6 nm |
Images and information placed above are from
http://www.airport-data.com/airport/1MD8/
We thank them for the data!
| General Info
|
| Country |
United States
|
| State |
MARYLAND
|
| FAA ID |
1MD8
|
| Latitude |
39-40-58.359N
|
| Longitude |
077-05-49.937W
|
| Elevation |
580 feet
|
| Near City |
WESTMINSTER/SILVER RUN
|
