Pentagon Air Force Heliport |
Location
& QuickFacts
|
FAA
Information Effective: |
2006-09-28 |
|
Airport
Identifier: |
JPN |
|
Longitude/Latitude: |
077-03-27.0000W/38-52-26.6000N
-77.057500/38.874056 (Estimated) |
|
Elevation: |
40 ft / 12.19 m (Estimated) |
|
Land: |
0 acres |
|
From
nearest city: |
0 nautical miles of Washington, DC |
|
Location: |
Washington County, DC |
|
Magnetic Variation: |
09W (1985) |
Owner
& Manager
|
Ownership: |
Army owned |
|
Owner: |
U.s.army Atca-aso |
|
Address: |
Cameron Sta
Alexandria, VA 22314 |
|
Address: |
|
|
Phone number: |
703-664-1201 |
Airport
Operations and Facilities
|
Airport
Use: |
Private |
|
Segmented
Circle: |
No |
|
Control
Tower: |
Yes |
|
Attendance
Schedule: |
ALL/MON-FRI/0730-1730
24 HR PPR V227-9250/225-4374. CLSD
WKEND & HOL. |
|
Sectional
chart: |
Washington |
|
Region: |
AEA - Eastern |
|
Boundary
ARTCC: |
ZDC - Washington |
|
Tie-in
FSS: |
DCA - Leesburg |
|
FSS
on Airport: |
No |
|
FSS
Phone: |
703-777-2856 |
|
FSS
Toll Free: |
1-800-WX-BRIEF |
|
Runway Information
Helipad H1
|
Dimension: |
82
x 82 ft / 25.0 x 25.0 m
PAD IS 131 FT ACROSS AND PENTAGON SHAPED. MEASUREMENT
IS APPROXIMATE. |
|
Surface: |
ASPH, |
|
Edge
Lights: |
Low |
|
|
Runway |
Runway |
|
Traffic
Pattern: |
Left |
Left |
|
Radio Navigation
Aids
|
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
|
GTN |
NDB |
Georgetown |
|
323.00 |
09W |
4.6 nm |
|
DC |
NDB |
Oxonn |
|
332.00 |
11W |
6.7 nm |
|
VKX |
NDB |
Potomac |
|
241.00 |
10W |
8.9 nm |
|
GAI |
NDB |
Gaithersburg |
|
385.00 |
09W |
18.5 nm |
|
BUH |
NDB |
Anne Arundel |
|
260.00 |
10W |
18.8 nm |
|
FND |
NDB |
Ellicott |
|
371.00 |
11W |
28.1 nm |
|
IUB |
NDB |
Institute |
|
404.00 |
08W |
32.0 nm |
|
GDX |
NDB |
Goodwin Lake |
|
227.00 |
08W |
36.5 nm |
|
MTN |
NDB |
Martin |
|
342.00 |
11W |
40.7 nm |
|
EZF |
NDB |
Shannon |
|
237.00 |
10W |
40.9 nm |
|
CJR |
NDB |
Culpeper |
|
252.00 |
09W |
42.8 nm |
|
ESN |
NDB |
Easton |
|
212.00 |
10W |
46.4 nm |
|
NHK |
NDB |
Patuxent |
|
400.00 |
10W |
46.8 nm |
|
APH |
NDB |
A P Hill |
|
396.00 |
10W |
48.9 nm |
|
TZ |
NDB |
Cogan |
|
364.00 |
10W |
48.9 nm |
|
MTN |
TACAN |
Martin |
068X |
|
11W |
40.8 nm |
|
FDK |
VOR |
Frederick |
|
109.00 |
08W |
35.6 nm |
|
DCA |
VOR/DME |
Washington |
047X |
111.00 |
09W |
1.3 nm |
|
ADW |
VORTAC |
Andrews |
078X |
113.10 |
10W |
9.8 nm |
|
OTT |
VORTAC |
Nottingham |
084X |
113.70 |
10W |
17.8 nm |
|
AML |
VORTAC |
Armel |
082X |
113.50 |
08W |
19.5 nm |
|
BAL |
VORTAC |
Baltimore |
098X |
115.10 |
11W |
25.7 nm |
|
BRV |
VORTAC |
Brooke |
092X |
114.50 |
09W |
35.2 nm |
|
EMI |
VORTAC |
Westminster |
126X |
117.90 |
08W |
37.5 nm |
|
CSN |
VORTAC |
Casanova |
110X |
116.30 |
06W |
40.4 nm |
|
PXT |
VORTAC |
Patuxent |
123X |
117.60 |
10W |
46.9 nm |
|
MRB |
VORTAC |
Martinsburg |
058X |
112.10 |
07W |
48.0 nm |
|
DCA |
VOT |
Washington National |
|
109.40 |
|
2.1 nm |
|
ADW |
VOT |
Andrews Afb |
|
109.60 |
|
9.8 nm |
Remarks
- OPR
1300-2100Z MON-FRI; CTC OIC C697-9250/695-4374; V227-9250/225-4374;
PRK RSTD TO CTL DISCRETION.
- C203-695-2776;
203-697-3658/697-8703; V225-2776/227-3658/227-8703. APVL LTD.
- (A31-H1)
HELIPAD DIMENSIONS UNKNOWN.
- SPECIAL
PRO; TFC PAT AND OPR RULES EXIST DUE TO WASHINGTON TCA; PRK; NOISE;
FLT PLAN COORDINATION AND VISUAL RTE RSTRNS.
- SPECIAL
VFR PERMITTED ONLY WHEN WASH NATL PAT CEIL/VIS IS 700 & 1 OR BETTER.
- ACFT
COMDR MUST HAVE RCV A RTE BRIEFING AND OPR WITH SPECIAL RTE CHART DTD
1 OCT 79; CONTAINING SPECIAL RTE AND JPN TFC PAT.
- TRANS
PILOTS BRIEFING ARE CONDUCTED AT DAVISON AAF, QUANTICO MCAS, ANDREWS
AFB OR TIPTON AAF.
- ADVN
24 HOUR FLT INFO WILL BE PASSED TO THE CTC OIC (PENTAGON HELIPORT) PRIOR
TO FLT TO INCLUDE:
- ARMY
COPTER PPR IS PQR FOR CODE 6 OR BELOW. CTC DIR ARMY STAFF (EXECUTIVE
SVC);
- AFTER
DUTY HOURS; CTC MILITARY DISTRICT OF WASHINGTON STAFF DUTY OFFICER (2
HOURS PPR) C202-693-1069/693-1193 OR V223-1193/223-1069.
- DATE
& TIME OF TKOF/LDG DEP/DESTN; TYPE OF ACFT/NR OF COPTERS INVOLVED;
NAME/GRADE SENIOR PERSONS AND NR OF ADDN PAX; PT OF CTC NADE AND FONE
NR.
Pentagon Ahp Heliport
Address:
Washington County, DC
Tel:
703-664-1201
Images
and information placed above are from
http://www.airport-data.com/airport/JPN/
We
thank them for the data!
| General
Info |
| Country |
United
States |
| State |
DIST.
OF COLUMBIA |
| FAA ID |
JPN
|
| Latitude |
38-52-12.403N
|
| Longitude |
077-03-38.918W
|
| Elevation |
37 feet
|
| Near City |
WASHINGTON
|
