Shoreline Clinic Heliport |
|
|
Location
& QuickFacts
|
FAA
Information Effective: |
2006-09-28 |
|
Airport
Identifier: |
CT97 |
|
Longitude/Latitude: |
072-25-41.3110W/41-19-44.3560N
-72.428142/41.328988 (Estimated) |
|
Elevation: |
59 ft / 17.98 m (Estimated) |
|
Land: |
0 acres |
|
From
nearest city: |
3 nautical miles W of Essex, CT |
|
Location: |
Middlesex County, CT |
|
Magnetic Variation: |
14W (1985) |
Owner
& Manager
|
Ownership: |
Privately owned |
|
Owner: |
Middlesex Hospital |
|
Address: |
28 Crescent Street
Middletown, CT 06457 |
|
Phone number: |
203-344-6570 |
|
Manager: |
Roger Quinley |
|
Address: |
28 Crescent Street
Middletown, CT 06457 |
|
Phone number: |
203-344-6570 |
Airport
Operations and Facilities
|
Airport
Use: |
Private
MEDICAL USE. |
|
Segmented
Circle: |
No |
|
Control
Tower: |
No |
|
Attendance
Schedule: |
UNATNDD |
|
Lighting
Schedule: |
PHONE REQ
FOR PERIMETER LGTS CALL 203-344-6570. |
|
Landing
fee charge: |
No |
|
Sectional
chart: |
New York |
|
Region: |
ANE - New England |
|
Boundary
ARTCC: |
ZBW - Boston |
|
Tie-in
FSS: |
BDR - Bridgeport |
|
FSS
on Airport: |
No |
|
FSS
Phone: |
866-293-5149 |
|
FSS
Toll Free: |
1-800-WX-BRIEF |
|
Runway Information
Helipad H1
|
Dimension: |
60 x 60 ft / 18.3 x 18.3 m |
|
Surface: |
ASPH, |
|
|
Runway H1 |
Runway |
|
Traffic
Pattern: |
Left |
Left |
|
Radio Navigation
Aids
|
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
|
HF |
NDB |
Lomis |
|
244.00 |
15W |
20.5 nm |
|
MMK |
NDB |
Meriden |
|
238.00 |
14W |
21.1 nm |
|
TBY |
NDB |
Waterbury |
|
257.00 |
14W |
34.4 nm |
|
OP |
NDB |
Old Field Point Light |
|
316.00 |
13W |
37.7 nm |
|
FOK |
TACAN |
Suffolk Co |
047X |
|
13W |
30.9 nm |
|
MAD |
VOR/DME |
Madison |
041X |
110.40 |
13W |
12.0 nm |
|
GON |
VOR/DME |
Groton |
45Y |
110.85 |
14W |
17.0 nm |
|
HFD |
VOR/DME |
Hartford |
096X |
114.90 |
13W |
19.5 nm |
|
HVN |
VOR/DME |
New Haven |
035X |
109.80 |
13W |
21.0 nm |
|
ORW |
VOR/DME |
Norwich |
037X |
110.00 |
14W |
23.7 nm |
|
CCC |
VOR/DME |
Calverton |
119X |
117.20 |
13W |
29.3 nm |
|
BDR |
VOR/DME |
Bridgeport |
25X |
108.80 |
12W |
33.1 nm |
|
SEY |
VOR/DME |
Sandy Point |
125X |
117.80 |
15W |
39.7 nm |
|
PUT |
VOR/DME |
Putnam |
121X |
117.40 |
14W |
45.9 nm |
|
HTO |
VORTAC |
Hampton |
083X |
113.60 |
13W |
25.2 nm |
|
BDL |
VORTAC |
Bradley |
027X |
109.00 |
14W |
38.6 nm |
|
GON |
VOT |
Groton |
|
110.25 |
|
17.0 nm |
|
HFD |
VOT |
Hartford |
|
108.20 |
|
26.4 nm |
|
BDR |
VOT |
Bridgeport |
|
109.25 |
|
33.1 nm |
|
BDL |
VOT |
Bradley Intl |
|
111.40 |
|
38.4 nm |
|
ISP |
VOT |
Long Island Mac Arthur |
|
109.40 |
|
44.4 nm |
Remarks
- VFR,
MEDICAL EMERGENCIES ONLY; INGRESS/EGRESS LIMITED TO 0 DEG TO 180 DEG;
AREA IS SECURED DURING OPERATIONS.
Shoreline Clinic Heliport
Address:
Middlesex County, CT
Tel:
203-344-6570
Images
and information placed above are from
http://www.airport-data.com/airport/CT97/
We
thank them for the data!
| General
Info |
| Country |
United
States |
| State |
CONNECTICUT
|
| FAA ID |
CT97
|
| Latitude |
41-19-44.356N
|
| Longitude |
072-25-41.311W
|
| Elevation |
59 feet
|
| Near City |
ESSEX
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
