Location
& QuickFacts
|
FAA Information Effective: |
2005-10-27 |
|
Airport Identifier: |
MXA |
|
Longitude/Latitude: |
090-09-16.4500W/35-53-40.0000N
-90.154569/35.894444 (Estimated) |
|
Elevation: |
242
ft / 73.76 m (Surveyed) |
|
Land: |
630 acres |
|
From nearest city: |
2
nautical miles NE of Manila, AR |
|
Location: |
Mississippi County, AR |
|
Magnetic Variation: |
01E
(1995) |
Owner &
Manager
|
Ownership: |
Publicly owned |
|
Owner: |
City
Of Manila |
|
Address: |
Po Box 895
Manila, AR 72442 |
|
Phone number: |
870-561-4437 |
|
Manager: |
Larry Davis |
|
Address: |
Box
1015
Manila, AR 72442 |
|
Phone number: |
870-561-4797 |
Airport
Operations and Facilities
|
Airport Use: |
Open to public |
|
Wind indicator: |
Yes |
|
Segmented Circle: |
Yes |
|
Control Tower: |
No |
|
Attendance Schedule: |
ALL/ALL/DALGT |
|
Lighting Schedule: |
DUSK-DAWN
ACTVT MIRL RY 18/36; PAPI RYS 18 & 36 - CTAF. |
|
Beacon Color: |
Clear-Green
(lighted land airport) |
|
Landing fee charge: |
No |
|
Sectional chart: |
Memphis |
|
Region: |
ASW
- Southwest |
|
Boundary ARTCC: |
ZME - Memphis |
|
Tie-in FSS: |
JBR
- Jonesboro |
|
FSS on Airport: |
No |
|
FSS Phone: |
870-935-3471 |
|
FSS Toll Free: |
1-800-WX-BRIEF |
|
NOTAMs Facility: |
JBR
(NOTAM-d service avaliable) |
|
Federal Agreements: |
NGRY |
Airport
Communications
|
CTAF: |
122.800 |
|
Unicom: |
122.800
|
Airport
Services
|
Fuel available: |
100LL
FOR SVC AFT HRS CALL 501-561-3322/4934/3233; NO FEE. 24 HR SELF
SERVICE FUEL AVBL WITH CREDIT CARD. |
|
Airframe Repair: |
MINOR |
|
Power Plant Repair: |
MINOR |
|
Bottled Oxygen: |
NONE |
|
Bulk Oxygen: |
NONE |
Runway
Information
Runway
18/36
|
Dimension: |
4200
x 60 ft / 1280.2 x 18.3 m |
|
Surface: |
ASPH,
Good Condition |
|
Weight Limit: |
Single wheel: 15000 lbs. |
|
Edge Lights: |
Medium |
| |
Runway 18 |
Runway 36 |
|
Longitude: |
090-09-16.3000W |
090-09-16.5870W |
|
Latitude: |
35-54-00.8000N |
35-53-19.2420N |
|
Elevation: |
240.00
ft |
242.00
ft |
|
Alignment: |
127 |
0 |
|
Traffic Pattern: |
Left |
Right |
|
Markings: |
Non-precision instrument, Fair Condition |
Non-precision instrument, Fair Condition |
|
Crossing Height: |
31.00
ft |
32.00
ft |
|
Displaced threshold: |
0.00 ft |
60.00 ft |
|
VASI: |
2-light PAPI on right side |
2-light PAPI on left side |
|
Visual Glide Angle: |
4.00° |
4.00° |
|
Obstruction: |
67 ft tree, 1820.0 ft from runway, 40 ft right of centerline,
24:1 slope to clear |
15 ft road, 460.0 ft from runway, 17:1 slope to clear
APCH SLOPE 34:1 TO DSPLCD THLD. |
|
Radio Navigation
Aids
|
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
|
MXA |
NDB |
Manila |
|
282.00 |
01E |
0.2 nm |
|
BPW |
NDB |
Osceola |
|
239.00 |
02E |
14.0
nm |
|
IUI |
NDB |
Hicks |
|
350.00 |
01E |
15.8 nm |
|
PGR |
NDB |
Paragould |
|
383.00 |
01E |
20.1
nm |
|
TKX |
NDB |
Kennett |
|
358.00 |
00E |
20.8 nm |
|
COO |
NDB |
Covington |
|
326.00 |
02E |
33.2
nm |
|
DNT |
NDB |
Nally Dunston |
|
343.00 |
01W |
36.9 nm |
|
MIG |
NDB |
Millington |
|
232.00 |
04E |
38.6
nm |
|
TNZ |
NDB |
Lawrence County |
|
227.00 |
01E |
41.8 nm |
|
SPQ |
NDB |
Spain |
|
414.00 |
04E |
42.0
nm |
|
AWM |
NDB |
West Memphis |
|
362.00 |
01E |
45.5 nm |
|
FD |
NDB |
Earli |
|
278.00 |
03E |
47.3
nm |
|
GOJ |
VOR |
Gosnell |
|
111.80 |
01E |
10.9 nm |
|
JBR |
VOR/DME |
Jonesboro |
023X |
108.60 |
02E |
21.2
nm |
|
GQE |
VOR/DME |
Gilmore |
077X |
113.00 |
04E |
36.5 nm |
|
ARG |
VORTAC |
Walnut
Ridge |
092X |
114.50 |
04E |
41.0
nm |
|
DYR |
VORTAC |
Dyersburg |
115X |
116.80 |
03E |
41.4 nm |
|
MAW |
VORTAC |
Malden |
049X |
111.20 |
03E |
41.4
nm |
Remarks
- NUMEROUS AGRICULTURAL
ACFT OPNS FM FEB-NOV 500 FT AGL & BLO.
Manila Municipal Airport
Address:
Mississippi
County, AR
Tel: 870-561-4797
|
General Info |
| Country |
United
States |
| State |
ARKANSAS
|
| FAA
ID |
MXA
|
| Latitude |
35-53-40.000N
|
| Longitude |
090-09-16.450W
|
| Elevation |
242
feet |
| Near
City |
MANILA
|
