Location & QuickFacts
| FAA
Information Effective: |
2005-10-27 |
| Airport
Identifier: |
CDH |
| Longitude/Latitude: |
092-45-48.2230W/33-37-22.0770N
-92.763395/33.622799 (Estimated) |
| Elevation: |
130
ft / 39.62 m (Surveyed) |
| Land: |
1146
acres |
| From
nearest city: |
5
nautical miles NE of Camden, AR |
| Location: |
Ouachita
County, AR |
| Magnetic
Variation: |
03E
(2000) |
Owner &
Manager
| Ownership: |
Publicly
owned |
| Owner: |
City
Of Camden |
| Address: |
Po Box
654
Camden, AR 71711 |
| Phone
number: |
870-836-6436 |
| Manager: |
David
Cicero, Chairman |
| Address: |
Ouachita
County, AR |
| Phone
number: |
870-574-9992 |
Airport
Operations and Facilities
| Airport
Use: |
Open
to public |
| Wind
indicator: |
Yes |
| Segmented
Circle: |
Yes |
| Control
Tower: |
No |
| Attendance
Schedule: |
ALL/ALL/0800-DUSK
FOR SERVICE AFT HRS CALL 870-864-6772 OR 870-231-6545. |
| Lighting
Schedule: |
DUSK-DAWN
ACTVT MIRL RY 18/36, PAPI RYS 18 & 36 AND REIL RYS 18 &
36 - CTAF. |
| Beacon
Color: |
Clear-Green
(lighted land airport) |
| Landing
fee charge: |
No |
| Sectional
chart: |
Memphis |
| Region: |
ASW
- Southwest |
| Boundary
ARTCC: |
ZFW
- Fort Worth |
| Tie-in
FSS: |
JBR
- Jonesboro |
| FSS
on Airport: |
No |
| FSS
Phone: |
870-935-3471 |
| FSS
Toll Free: |
1-800-WX-BRIEF |
| NOTAMs
Facility: |
JBR
(NOTAM-d service avaliable) |
| Federal
Agreements: |
NGPSXY |
Airport
Communications
| CTAF: |
122.700 |
| Unicom: |
122.700
|
Airport
Services
| Fuel
available: |
100LLA |
| Airframe
Repair: |
MAJOR |
| Power
Plant Repair: |
MAJOR |
| Bottled
Oxygen: |
NONE |
Runway
Information
Runway
18/36
| Dimension: |
6501
x 100 ft / 1981.5 x 30.5 m |
| Surface: |
ASPH,
Good Condition |
| Weight
Limit: |
Single
wheel: 86000 lbs.
Dual wheel: 112000 lbs.
Dual tandem wheel: 180000 lbs. |
| Edge
Lights: |
Medium |
| |
Runway
18 |
Runway
36 |
| Longitude: |
092-45-42.1660W |
092-45-54.2780W |
| Latitude: |
33-37-53.8340N |
33-36-50.3200N |
| Elevation: |
130.00
ft |
123.00
ft |
| Alignment: |
127 |
9 |
| Traffic
Pattern: |
Left |
Left |
| Markings: |
Non-precision
instrument, Good Condition |
Non-precision
instrument, Good Condition |
| Crossing
Height: |
25.00
ft |
25.00
ft |
| VASI: |
2-light
PAPI on left side |
2-light
PAPI on left side |
| Visual
Glide Angle: |
3.00° |
3.00° |
| Runway
End Identifier: |
Yes |
Yes |
| Obstruction: |
25
ft trees, 318.0 ft from runway, 4:1 slope to clear |
20
ft trees, 1050.0 ft from runway, 250 ft left of centerline,
42:1 slope to clear |
|
Radio Navigation
Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| CDH |
NDB |
Camden |
|
335.00 |
03E |
0.6
nm |
|
ADF |
NDB |
Arkadelphia |
|
275.00 |
02E |
31.1
nm |
| AGO |
NDB |
Magnolia |
|
266.00 |
04E |
32.9
nm |
|
REN |
NDB |
Warren |
|
226.00 |
04E |
33.7
nm |
| MVQ |
NDB |
Malvern |
|
215.00 |
04E |
42.7
nm |
|
HPC |
NDB |
Hope |
|
362.00 |
03E |
44.7
nm |
| ELD |
VORTAC |
El
Dorado |
102X |
115.50 |
07E |
22.1
nm |
Remarks
- DEER ON & INVOF ARPT.
- ULTRALIGHT
ACTIVITY ON & INVOF ARPT.
Harrell Field Airport
Address: Ouachita County,
AR
Tel: 870-574-9992
 |
