Frank Federer Memorial Airport |
Location
& QuickFacts
| FAA
Information Effective: |
2005-10-27 |
| Airport
Identifier: |
M36 |
| Longitude/Latitude: |
091-10-35.1870W/34-52-48.9850N
-91.176441/34.880274 (Estimated) |
| Elevation: |
194
ft / 59.13 m (Surveyed) |
| Land: |
166
acres |
| From
nearest city: |
0
nautical miles SE of Brinkley, AR |
| Location: |
Monroe
County, AR |
| Magnetic
Variation: |
02E
(1995) |
Owner &
Manager
| Ownership: |
Publicly
owned |
| Owner: |
City
Of Brinkley |
| Address: |
233
West Cedar
Brinkley, AR 72021 |
| Phone
number: |
870-734-1382 |
| Manager: |
Jim
Pugh, Airport Commissioner |
| Address: |
233
West Cedar
Brinkley, AR 72021 |
| Phone
number: |
870-734-1933 |
Airport
Operations and Facilities
| Airport
Use: |
Open
to public |
| Wind
indicator: |
Yes |
| Segmented
Circle: |
No |
| Control
Tower: |
No |
| Attendance
Schedule: |
MAR-SEP/ALL/0800-1700,OCT-FEB/MON-FRI/0800-1700 |
| Lighting
Schedule: |
DUSK-DAWN
ACTVT MIRL RY 02/20 - CTAF. |
| Beacon
Color: |
Clear-Green
(lighted land airport)
ROTG BCN OTS INDEFLY. |
| Landing
fee charge: |
No |
| Sectional
chart: |
Memphis |
| Region: |
ASW
- Southwest |
| Traffic
Pattern Alt: |
1000
ft |
| Boundary
ARTCC: |
ZME
- Memphis |
| Tie-in
FSS: |
JBR
- Jonesboro |
| FSS
on Airport: |
No |
| FSS
Phone: |
870-935-3471 |
| FSS
Toll Free: |
1-800-WX-BRIEF |
| NOTAMs
Facility: |
JBR
(NOTAM-d service avaliable) |
| Federal
Agreements: |
NGY |
Airport
Communications
| CTAF: |
122.800 |
| Unicom: |
122.800
|
Airport
Services
| Fuel
available: |
100LL |
| Airframe
Repair: |
MAJOR |
| Power
Plant Repair: |
MAJOR |
Runway
Information
Runway
02/20
| Dimension: |
4005
x 50 ft / 1220.7 x 15.2 m |
| Surface: |
ASPH,
Good Condition |
| Weight
Limit: |
Single wheel: 12000
lbs. |
| Edge
Lights: |
Medium |
| |
Runway
02 |
Runway
20 |
| Longitude: |
091-10-45.6530W |
091-10-24.7200W |
| Latitude: |
34-52-31.1570N |
34-53-06.8120N |
| Elevation: |
194.00
ft |
190.00
ft |
| Alignment: |
26 |
127 |
| Traffic
Pattern: |
Right |
Left |
| Markings: |
Non-precision
instrument, Good Condition |
Non-precision
instrument, Good Condition |
| Crossing
Height: |
45.00
ft |
45.00
ft |
| Displaced
threshold: |
250.00 ft |
150.00 ft |
| VASI: |
2-light
PAPI on left side |
2-light
PAPI on left side |
| Visual
Glide Angle: |
3.00° |
3.00° |
| Obstruction: |
20
ft tree, 600.0 ft from runway, 150 ft right of centerline,
20:1 slope to clear
APCH SLOPE 50:1 TO DSPLCD THLD.
ROAD & BRIDGE SIGNS AT 180 FT FM THLD CROSSING
CNTRLN. |
24
ft brush, 350.0 ft from runway, 90 ft left of centerline,
6:1 slope to clear
APCH SLOPE 20:1 TO DSPLCD THLD. |
|
Radio Navigation
Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| FCY |
NDB |
Forrest
City |
|
332.00 |
01E |
20.2
nm |
|
SGT |
NDB |
Stuttgart |
|
269.00 |
02E |
24.3
nm |
| HEE |
NDB |
Thompson-robbins |
|
251.00 |
01E |
30.9
nm |
|
SRC |
NDB |
Searcy |
|
323.00 |
02E |
33.9
nm |
| TYV |
NDB |
Toneyville |
|
290.00 |
04E |
41.8
nm |
|
EWP |
NDB |
Newport |
|
400.00 |
04E |
45.8
nm |
| CKM |
NDB |
Clarksdale |
|
341.00 |
02E |
48.1
nm |
|
AWM |
NDB |
West
Memphis |
|
362.00 |
01E |
49.0
nm |
| LRF |
TACAN |
Jacksonville |
029X |
|
04E |
48.4
nm |
|
UJM |
VOR/DME |
Marvell |
033X |
109.60 |
01E |
30.8
nm |
| GQE |
VOR/DME |
Gilmore |
077X |
113.00 |
04E |
44.3
nm |
Remarks
- WATER-TANK NW.
- NUMEROUS
AGRICULTURAL ACFT OPNS FM FEB-NOV 500 FT AGL AND BELOW.
- PAEW ADJ RY 02/20.
Frank Federer Memorial
Airport
Address: Monroe County,
AR
Tel: 870-734-1933
Images and information placed
above are from
http://www.airport-data.com/airport/M36/
We
thank them for the data!
|
General Info |
| Country |
United
States |
| State |
ARKANSAS
|
| FAA
ID |
M36
|
| Latitude |
34-52-48.985N
|
| Longitude |
091-10-35.187W
|
| Elevation |
194
feet |
| Near
City |
BRINKLEY
|
We don't guarantee the information is fresh and accurate. The data may be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
