Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | JWY |
| Airport Status: | Operational |
| Longitude/Latitude: | 096-54-45.7000W/32-27-22.4000N
-96.912694/32.456222 (Estimated) |
| Elevation: | 713 ft / 217.32 m (Surveyed) |
| Land: | 243 acres |
| From nearest city: | 5 nautical miles SE of Midlothian/waxahachie, TX |
| Location: | Ellis County, TX |
| Magnetic Variation: | 06E (1995) |
Owner & Manager
| Ownership: | Publicly owned |
| Owner: | Midlothian & Waxahachie City |
| Address: | Po Box 757
Waxahachie, TX 75150 |
| Phone number: | 972-937-7330 |
| Manager: | Cam Fearis |
| Address: | 131 Airport Rd
Midlothian, TX 76065 |
| Phone number: | 972-923-0080
EMERGENCY PHONE: 214-680-9869. |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | Yes |
| Control Tower: | No |
| Lighting Schedule: | DUSK-DAWN |
| Beacon Color: | Clear-Green (lighted land airport) |
| Sectional chart: | Dallas-ft Worth |
| Region: | ASW - Southwest |
| Boundary ARTCC: | ZFW - Fort Worth |
| Tie-in FSS: | FTW - Fort Worth |
| FSS on Airport: | No |
| FSS Phone: | 817-541-3474 |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | JWY (NOTAM-d service avaliable) |
| Federal Agreements: | NGY |
Airport Communications
| CTAF: | 122.975 |
| Unicom: | 122.975 |
Airport Services
| Fuel available: | 100LLA
FOR FUEL & SERVICES AFT HRS CALL 469-693-3905. |
| Airframe Repair: | MAJOR |
| Power Plant Repair: | MAJOR |
| Bottled Oxygen: | HIGH |
Runway Information
Runway 18/36
| Dimension: | 4999 x 75 ft / 1523.7 x 22.9 m |
| Surface: | ASPH, Good Condition |
| Weight Limit: | Single wheel: 30000 lbs. |
| Edge Lights: | Medium |
| |
Runway 18 |
Runway 36 |
| Longitude: | 096-54-43.6729W | 096-54-47.7259W |
| Latitude: | 32-27-47.1216N | 32-26-57.7743N |
| Elevation: | 713.00 ft | 686.00 ft |
| Alignment: | 127 | 4 |
| Traffic Pattern: | Left | Left |
| Markings: | Non-precision instrument, Good Condition | Non-precision instrument, Good Condition |
| Crossing Height: | 41.00 ft | 25.00 ft |
| VASI: | 4-light PAPI on right side | 2-light PAPI on left side |
| Visual Glide Angle: | 3.00° | 3.50° |
| Obstruction: | 72 ft pline, 1800.0 ft from runway, 200 ft left of centerline, 22:1 slope to clear | , 50:1 slope to clear |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| XQH | NDB | Cedar Hill | | 353.00 | 08E | 8.7 nm |
| LNC | NDB | Lancaster | | 239.00 | 06E | 12.1 nm |
| RBD | NDB | Redbird | | 287.00 | 06E | 13.4 nm |
| JUG | NDB | Jecca | | 388.00 | 06E | 23.1 nm |
| PQF | NDB | Mesquite | | 248.00 | 06E | 28.8 nm |
| CGQ | NDB | Powell | | 344.00 | 06E | 34.1 nm |
| CRS | NDB | Corsicana | | 396.00 | 06E | 36.8 nm |
| AVZ | NDB | Travis | | 260.00 | 06E | 38.2 nm |
| MII | NDB | Caddo Mills | | 316.00 | 06E | 48.6 nm |
| NFW | TACAN | Nas Jrb Fort Worth | 024X | | 07E | 32.7 nm |
| TTT | VOR/DME | Maverick | 078X | 113.10 | 06E | 25.6 nm |
| CVE | VOR/DME | Cowboy | 109X | 116.20 | 06E | 26.1 nm |
| FUZ | VORTAC | Ranger | 104X | 115.70 | 06E | 29.3 nm |
| CQY | VORTAC | Cedar Creek | 095X | 114.80 | 06E | 38.8 nm |
| DAL | VOT | Dallas Love Field | | 113.30 | | 23.7 nm |
| FTW | VOT | Fort Worth Meacham | | 108.20 | | 31.3 nm |
Remarks
- WILD PIGS ON & INVOF RY AFT DARK.
- ARPT PHONE NR 214-282-7196.
Images and information placed above are from
http://www.airport-data.com/airport/JWY/
We thank them for the data!
| General Info
|
| Country |
United States
|
| State |
TEXAS
|
| FAA ID |
JWY
|
| Time |
UTC-6(-5DT)
|
| Latitude |
32.456097
32° 27' 21.95" N
|
| Longitude |
-96.912411
096° 54' 44.68" W
|
| Elevation |
713 feet
217 meters
|
| Type |
Civil
|
| Magnetic Variation |
004° E (01/06)
|
| Beacon |
Yes
|
| Operating Agency |
U.S.CIVIL AIRPORT WHEREIN PERMIT COVERS USE BY TRANSIT MILITARY AIRCRAFT
|
| Near City |
Midlothian Waxahachie
|
| Operating Hours |
SEE REMARKS FOR OPERATING HOURS OR COMMUNICATIONS FOR POSSIBLE HOURS
|
| Daylight Saving Time |
Second Sunday in March at 0200 to first Sunday in November at 0200 local time (Exception Arizona and that portion of Indiana in the Eastern Time Zone)
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
