Chevron Chemical Co Heliport |
Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | TA98 |
| Airport Status: | Operational |
| Longitude/Latitude: | 094-55-22.7320W/29-49-17.8040N
-94.922981/29.821612 (Estimated) |
| Elevation: | 28 ft / 8.53 m (Estimated) |
| Land: | 1 acres |
| From nearest city: | 4 nautical miles N of Baytown, TX |
| Location: | Harris County, TX |
| Magnetic Variation: | 06E (1985) |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | Chevron Chemical Company |
| Address: | Po Box 509
Baytown, TX 77522 |
| Phone number: | 713-421-6500 |
| Manager: | L. A. Lucchesi |
| Address: | Po Box 509
Baytown, TX 77522 |
| Phone number: | 713-421-6200 |
Airport Operations and Facilities
| Airport Use: | Private |
| Wind indicator: | Yes |
| Segmented Circle: | No |
| Control Tower: | No |
| Lighting Schedule: | PHONE REQ
FOR PERIMETER LGTS CALL 713-421-6313 |
| Landing fee charge: | No |
| Sectional chart: | Houston |
| Region: | ASW - Southwest |
| Boundary ARTCC: | ZHU - Houston |
| Tie-in FSS: | CXO - Montgomery County |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF
FOR FP FILING CALL CXO FSS 1-800-833-5602. |
Runway Information
Helipad H1
| Dimension: | 40 x 40 ft / 12.2 x 12.2 m
TOUCHDOWN AREA 40' X 40' WITHIN A 200' X 200' LNDG/TKOF AREA. |
| Surface: | CONC, |
| |
Runway H1 |
Runway |
| Traffic Pattern: | Left | Left |
| Obstruction: | 25 ft trees, 200.0 ft from runway | |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| JPA | NDB | Sanjac | | 347.00 | 05E | 12.0 nm |
| CBC | NDB | Anahuac | | 413.00 | 05E | 13.9 nm |
| BVP | NDB | Nixin | | 326.00 | 05E | 18.4 nm |
| GLS | NDB | Galveston | | 206.00 | 08E | 30.6 nm |
| SYG | NDB | Sandy Point | | 402.00 | 05E | 34.4 nm |
| EYQ | NDB | Weiser | | 286.00 | 06E | 38.0 nm |
| DWH | NDB | David Hooks | | 521.00 | 05E | 38.1 nm |
| LYD | NDB | Lakeside | | 249.00 | 05E | 39.4 nm |
| SGR | NDB | Hull | | 388.00 | 05E | 39.9 nm |
| GDE | NDB | Goodhue | | 368.00 | 07E | 40.4 nm |
| HRD | NDB | Hardin County | | 524.00 | 04E | 46.4 nm |
| EFD | TACAN | Ellington | 031X | | 05E | 17.9 nm |
| MHF | VOR/DME | Trinity | 083X | 113.60 | 07E | 18.9 nm |
| HUB | VOR/DME | Hobby | 118X | 117.10 | 05E | 21.0 nm |
| SBI | VOR/DME | Sabine Pass | 101X | 115.40 | 07E | 46.9 nm |
| BPT | VOR/DME | Beaumont | 092X | 114.50 | 07E | 47.8 nm |
| IAH | VORTAC | Humble | 113X | 116.60 | 05E | 23.5 nm |
| DAS | VORTAC | Daisetta | 116X | 116.90 | 05E | 26.4 nm |
| VUH | VORTAC | Scholes | 077X | 113.00 | 06E | 33.3 nm |
| HOU | VOT | Houston Wm P Hobby | | 108.40 | | 21.4 nm |
Remarks
- (A52-H1-1) HELIPAD SURROUNDED BY CHEMICAL PLANT ON ALL SIDES EXCP SOUTH WITH UNLGTD/LGTD OBSTNS TO 350' ABOVE GRND LVL.
- VFR CONDS ONLY.
Images and information placed above are from
http://www.airport-data.com/airport/TA98/
We thank them for the data!
| General Info
|
| Country |
United States
|
| State |
TEXAS
|
| FAA ID |
TA98
|
| Latitude |
29-49-17.804N
|
| Longitude |
094-55-22.732W
|
| Elevation |
28 feet
|
| Near City |
BAYTOWN
|
