Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | GAF |
| Airport Status: | Operational |
| Longitude/Latitude: | 097-22-15.4000W/48-24-17.0000N
-97.370944/48.404722 (Estimated) |
| Elevation: | 824 ft / 251.16 m (Surveyed) |
| Land: | 250 acres |
| From nearest city: | 2 nautical miles SE of Grafton, ND |
| Location: | Walsh County, ND |
| Magnetic Variation: | 06E (2000) |
Owner & Manager
| Ownership: | Publicly owned |
| Owner: | Grafton Arpt Auth
CHAIRMAN ARPT AUTH GEORGE LORANGER |
| Address: | Box 5
Grafton, ND 58237 |
| Phone number: | 701-352-3989
CELL PHONE (701) 520-8304 |
| Manager: | Wayne Gerszewski |
| Address: | 15182 Hwy 17
Grafton, ND 58237 |
| Phone number: | 701-352-0271
APT MGRS CELL NUMBER 701-360-2295 |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | Yes |
| Control Tower: | No |
| Lighting Schedule: | DUSK-DAWN
MIRL RY 17/35 & PAPI RYS 17 & 35 PRESET ON LOW INTST DUSK-2200; TO INCR INTST AFT 2200 ACTVT - CTAF. |
| Beacon Color: | Clear-Green (lighted land airport) |
| Landing fee charge: | No |
| Sectional chart: | Twin Cities |
| Region: | AGL - Great Lakes |
| Boundary ARTCC: | ZMP - Minneapolis |
| Tie-in FSS: | GFK - Grand Forks |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | GFK (NOTAM-d service avaliable) |
| Federal Agreements: | NGY |
Airport Communications
| CTAF: | 122.800 |
| Unicom: | 122.800 |
Airport Services
| Fuel available: | 100LLA
24-HR SELF- SERVICE FUEL AVBL WITH CREDIT CARD ONLY. |
| Airframe Repair: | MINOR |
| Power Plant Repair: | MINOR |
| Bottled Oxygen: | NONE |
| Bulk Oxygen: | NONE |
Runway Information
Runway 08/26
| Dimension: | 4074 x 115 ft / 1241.8 x 35.1 m |
| Surface: | TURF, Poor Condition
TURF SOFT WHEN WET & ROUGH DUE TO SPARSE GRASS GROWTH.
RY BREAKING ACTION POOR WHEN WET. |
| |
Runway 08 |
Runway 26 |
| Longitude: | 097-23-03.0887W | 097-22-02.7099W |
| Latitude: | 48-24-14.6252N | 48-24-14.3566N |
| Elevation: | 821.00 ft | 821.00 ft |
| Alignment: | 90 | 127 |
| Traffic Pattern: | Left | Left |
| Obstruction: | 40 ft pline, 1900.0 ft from runway, 47:1 slope to clear | 19 ft road, 400.0 ft from runway, 21:1 slope to clear |
|
Runway 17/35
| Dimension: | 3898 x 74 ft / 1188.1 x 22.6 m |
| Surface: | ASPH, Good Condition
TURF SOFT WHEN WET & ROUGH DUE TO SPARSE GRASS GROWTH.
RY BREAKING ACTION POOR WHEN WET. |
| Surface Treatment: | Aggregate Friction Seal Coat |
| Weight Limit: | Single wheel: 12500 lbs. |
| Edge Lights: | Medium |
| |
Runway 17 |
Runway 35 |
| Longitude: | 097-21-57.1772W | 097-21-57.2025W |
| Latitude: | 48-24-38.8045N | 48-24-00.3414N |
| Elevation: | 822.00 ft | 821.00 ft |
| Alignment: | 127 | 127 |
| Traffic Pattern: | Left | Left |
| Markings: | Non-precision instrument, Fair Condition | Non-precision instrument, Fair Condition |
| Crossing Height: | 25.00 ft | 25.00 ft |
| VASI: | 2-light PAPI on left side | 2-light PAPI on left side |
| Visual Glide Angle: | 3.00° | 3.00° |
| Obstruction: | 20 ft road, 600.0 ft from runway, 20:1 slope to clear | 18 ft road, 725.0 ft from runway, 29:1 slope to clear |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| CKN | NDB | Crookston | | 400.00 | 07E | 45.5 nm |
| RDR | TACAN | Red River | 111X | | 06E | 26.9 nm |
| GFK | VOR/DME | Grand Forks | 090X | 114.30 | 09E | 28.0 nm |
| HML | VORTAC | Humboldt | 071X | 112.40 | 09E | 29.7 nm |
Remarks
- CTN: 3'DITCH BTN EAST END 8/26 & 17/35, USE DSGND TWYS.
- LARGE BIRDS ON OR INVOF OF ARPT.
- HEAVY AERIAL SPRAY ACTIVITY MAY-SEP.
- CONFIRM WINTER CONDS AND SNOW REMOVAL WITH AMGR CALL 701-352-0271 OR 701-360-2295 OR 701-520-9174.
- NMRS TSNT FLT TRNG ACTIVITIES.
- RY 17/35 PARALLEL TWY MARKED WITH REFLECTORS.
- PONDED WATER BETWEEN RY 17/35 & PARALLEL TWY.
Images and information placed above are from
http://www.airport-data.com/airport/GAF/
We thank them for the data!
| General Info
|
| Country |
United States
|
| State |
NORTH DAKOTA
|
| FAA ID |
GAF
|
| Latitude |
48-24-16.900N
|
| Longitude |
097-22-15.400W
|
| Elevation |
824 feet
|
| Near City |
GRAFTON
|
Thanks to: www.worldaerodata.com
