Location
& QuickFacts
|
FAA Information Effective: |
2007-01-18 |
|
Airport
Identifier: |
06FA |
|
Airport
Status: |
Operational |
|
Longitude/Latitude: |
080-19-44.1750W/26-54-30.2070N
-80.328937/26.908391 (Estimated) |
|
Elevation: |
28
ft / 8.53 m (Estimated) |
|
Land: |
0
acres |
|
From
nearest city: |
24 nautical miles S of Jupiter, FL |
|
Location: |
Palm Beach County, FL |
|
Magnetic Variation: |
03W (1985) |
Owner
& Manager
|
Ownership: |
Privately owned |
|
Owner: |
United Technologies Corp |
|
Address: |
Po Box 109630
Palm Beach Gardens, FL 33410 |
|
Phone
number: |
561-796-5830 |
|
Manager: |
Steven Fulton |
|
Address: |
Po Box 109610
West Palm Beach, FL 33410-9610 |
|
Phone number: |
561-775-5452 |
Airport
Operations and Facilities
|
Airport Use: |
Private |
|
Wind
indicator: |
Yes |
|
Segmented
Circle: |
No |
|
Control
Tower: |
Yes |
|
Lighting
Schedule: |
ATC-CTL |
|
Beacon
Color: |
Clear-Green (lighted land airport) |
|
Landing
fee charge: |
No |
|
Sectional
chart: |
Miami |
|
Region: |
ASO - Southern |
|
Boundary
ARTCC: |
ZMA - Miami |
|
Tie-in
FSS: |
MIA - Miami |
|
FSS
on Airport: |
No |
|
FSS
Phone: |
305-233-2600 |
|
FSS
Toll Free: |
1-800-WX-BRIEF |
|
Runway Information
Runway 09/27
|
Dimension: |
7003 x 150 ft / 2134.5 x 45.7 m |
|
Surface: |
ASPH, |
|
Pavement
Class: |
49 /F/A/X/T |
|
Edge
Lights: |
High |
|
|
Runway 09 |
Runway 27 |
|
Longitude: |
080-20-20.9680W |
080-19-03.6130W |
|
Latitude: |
26-54-29.3410N |
26-54-29.3610N |
|
Elevation: |
28.00
ft |
28.00
ft |
|
Alignment: |
90 |
127 |
|
ILS
Type: |
ILS/DME |
|
|
Traffic
Pattern: |
Left |
Right |
|
Crossing
Height: |
58.00
ft |
0.00 ft |
|
Displaced
threshold: |
241.00
ft |
241.00
ft |
|
VASI: |
4-light PAPI on left side |
4-light PAPI on left side |
|
Visual
Glide Angle: |
3.00° |
3.00° |
|
Runway
End Identifier: |
Yes |
Yes |
|
Radio Navigation
Aids
|
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
|
UTX |
NDB |
United |
|
405.00 |
03W |
0.3 nm |
|
PB |
NDB |
Rubin |
|
356.00 |
03W |
14.7 nm |
|
FPR |
NDB |
Fort Pierce |
|
275.00 |
04W |
34.8 nm |
|
FX |
NDB |
Praiz |
|
221.00 |
02W |
43.5 nm |
|
VEP |
NDB |
Vero Beach |
|
392.00 |
04W |
45.7 nm |
|
PJN |
NDB |
Plantation |
|
242.00 |
03W |
47.0 nm |
|
PBI |
VORTAC |
Palm Beach |
104X |
115.70 |
03W |
18.9 nm |
|
PHK |
VORTAC |
Pahokee |
101X |
115.40 |
00E |
20.9 nm |
|
VRB |
VORTAC |
Vero Beach |
120X |
117.30 |
04W |
47.1 nm |
|
PBI |
VOT |
Palm Beach |
|
109.00 |
|
18.0 nm |
|
VRB |
VOT |
Vero Beach |
|
111.00 |
|
45.1 nm |
Remarks
- OPEN
ONLY TO CIVIL & MIL ACFT HAVING BUSINESS WITH UNITED TECHNOLOGIES
CORPORATION OR ITS DIVISIONS. PPR
CTC ATCT C561-775-5450.
- ARPT
BCN OPERS ONLY WHEN ARPT IS ATTENDED.
- FUEL:
NOT FOR PUBLIC SALE. A, J5 J8 FLUID - SP.
- JASU:
(4 HOBART STARTING UNITS 28.5V/750 AMPS.)
- MISC:
COPTER OPR. VERT TKOF UP TO 3000'. POSSIBLE VERT JET TURBULENCE WITHIN
2 NM OF APCH END RWY 09. CLASS D AIRSPACE EFF 1200-2300Z++ MON-FRI,
OT CLASS G.
Based
Aircraft
|
Aircraft
based on field: |
11 |
|
Jet Engine
Airplanes: |
1 |
|
Helicopters: |
10 |
William P Gwinn Airport
Address:
Palm Beach County, FL
Tel:
561-796-5830,
561-775-5452
