Little Rock Air Force Base (Afb) Airport |
Location
& QuickFacts
|
FAA Information Effective: |
2005-10-27 |
|
Airport Identifier: |
LRF |
|
Longitude/Latitude: |
092-08-47.4000W/34-55-05.4000N
-92.146500/34.918167 (Estimated) |
|
Elevation: |
311
ft / 94.79 m (Surveyed) |
|
Land: |
0 acres |
|
From nearest city: |
1
nautical miles SE of Jacksonville, AR |
|
Location: |
Pulaski County, AR |
|
Magnetic Variation: |
04E
(1985) |
Owner &
Manager
|
Ownership: |
Air Force owned |
|
Owner: |
Usaf,
Mac |
|
Address: |
Little
Rock Afb
Jacksonville, AR 72076 |
|
Manager: |
Chief
Of Afld Management |
|
Address: |
Little
Rock Afb
Jacksonville, AR 72076 |
|
Phone number: |
501-988-3131 |
Airport
Operations and Facilities
|
Wind indicator: |
Yes |
|
Segmented Circle: |
No |
|
Control Tower: |
Yes |
|
Attendance Schedule: |
ALL/ALL/ALL
CLSD HOL FROM 0300Z++ PRECEDING DAY THRU 1300Z++ SUCCEEDING DAY.
HOL ON MON, CLSD 0500Z++ PRECEDING FRI THRU 1300Z++ SUCCEEDING TUE.
CLSD 0300Z++ 24 DEC THRU 1300Z++ 26 DEC. CLSD 0300Z++ 31 DEC THRU
1300Z++ 2 JAN. |
|
Lighting Schedule: |
DUSK-DAWN |
|
Beacon Color: |
Clear-Green
(lighted land airport) |
|
Sectional chart: |
Memphis |
|
Region: |
ASW
- Southwest |
|
Boundary ARTCC: |
ZME - Memphis |
|
Tie-in FSS: |
JBR
- Jonesboro |
|
FSS on Airport: |
No |
|
FSS Phone: |
870-935-3471 |
|
FSS Toll Free: |
1-800-WX-BRIEF |
|
NOTAMs Facility: |
LIT
(NOTAM-d service avaliable) |
|
Wind indicator: |
Yes |
|
Segmented Circle: |
No |
|
Control Tower: |
Yes |
|
Attendance Schedule: |
ALL/ALL/ALL
CLSD HOL FROM 0300Z++ PRECEDING DAY THRU 1300Z++ SUCCEEDING DAY.
HOL ON MON, CLSD 0500Z++ PRECEDING FRI THRU 1300Z++ SUCCEEDING TUE.
CLSD 0300Z++ 24 DEC THRU 1300Z++ 26 DEC. CLSD 0300Z++ 31 DEC THRU
1300Z++ 2 JAN. |
|
Lighting Schedule: |
DUSK-DAWN |
|
Beacon Color: |
Clear-Green
(lighted land airport) |
|
Sectional chart: |
Memphis |
|
Region: |
ASW
- Southwest |
|
Boundary ARTCC: |
ZME - Memphis |
|
Tie-in FSS: |
JBR
- Jonesboro |
|
FSS on Airport: |
No |
|
FSS Phone: |
870-935-3471 |
|
FSS Toll Free: |
1-800-WX-BRIEF |
|
NOTAMs Facility: |
LIT
(NOTAM-d service avaliable) |
Runway
Information
Runway
069/249
|
Dimension: |
3500
x 60 ft / 1066.8 x 18.3 m |
|
Surface: |
ASPH,
|
|
|
Runway 069 |
Runway 249 |
|
Traffic Pattern: |
Left |
Left |
|
Markings: |
None, |
None, |
|
Runway End Identifier: |
No |
No |
|
Centerline Lights: |
No |
No |
|
Touchdown Lights: |
No |
No |
|
Runway
07/25
|
Dimension: |
12000
x 200 ft / 3657.6 x 61.0 m |
|
Surface: |
CONC,
|
|
Weight Limit: |
Single
wheel: 125000 lbs.
Dual wheel: 200000 lbs.
Dual tandem wheel: 330000 lbs.
Dual dual tandem wheel: 820000 lbs. |
|
Edge Lights: |
High |
|
|
Runway 07 |
Runway 25 |
|
Longitude: |
092-09-55.6800W |
092-07-39.4200W |
|
Latitude: |
34-54-41.0300N |
34-55-19.7100N |
|
Elevation: |
286.00
ft |
290.00
ft |
|
ILS Type: |
MLS |
ILS |
|
Traffic Pattern: |
Left |
Right |
|
Markings: |
Precision instrument, |
Precision instrument, |
|
VASI: |
4-light PAPI on left side |
4-light PAPI on left side |
|
RVR Equipment: |
touchdown |
touchdown |
|
Approach lights: |
ALSF1 |
ALSF1 |
|
Runway End Identifier: |
No |
No |
|
Centerline Lights: |
No |
No |
|
Touchdown Lights: |
No |
No |
|
Radio Navigation
Aids
|
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
|
TYV |
NDB |
Toneyville |
|
290.00 |
04E |
6.6 nm |
|
CWS |
NDB |
Conway |
|
302.00 |
05E |
17.0
nm |
|
SRC |
NDB |
Searcy |
|
323.00 |
02E |
27.0 nm |
|
BDQ |
NDB |
Bridge |
|
208.00 |
04E |
30.9
nm |
|
SGT |
NDB |
Stuttgart |
|
269.00 |
02E |
31.3 nm |
|
HBZ |
NDB |
Heber
Springs |
|
256.00 |
03E |
36.4
nm |
|
MPJ |
NDB |
Morrilton |
|
410.00 |
07E |
40.2 nm |
|
MVQ |
NDB |
Malvern |
|
215.00 |
04E |
46.5
nm |
|
BKZ |
NDB |
Brinkley |
|
242.00 |
02E |
47.8 nm |
|
LRF |
TACAN |
Jacksonville |
029X |
|
04E |
0.6
nm |
|
PBF |
VOR/DME |
Pine Bluff |
107X |
116.00 |
04E |
41.8 nm |
|
LIT |
VORTAC |
Little
Rock |
086X |
113.90 |
05E |
14.6
nm |
Remarks
- RSTD: PPR EXCP AIREVAC
& ARMED FORCES COURIER.
- RSTD: OFFL BUS ONLY 1700-2100Z++
WKD EXC AIREVAC AND ARMED FORCES CARRIER. OBTAIN PPR 72 HRS PRIOR TO
ARRIVAL. CALL DSN 731-6123, PPR IS VALID +/- 30 MIN OF PROPOSED ETA.
- CAUTION: HI POTENTIAL
FOR HYDROPLANING ON RWY 07-25 DUR PERIODS OF WET WX.
- RSTD: MIN 24 HR PN RQR
FOR B52 ACFT GND SUPPORT.
- CAUTION: NUMEROUS UNLGTD
OBST LCTD PRIM SFC.
- CAUTION: NSTD RWY MRK-
ASSAULT STRIP MRK (3500' X 60') PAINTED ON RWY 25.
- MISC: ALL TRANSIENT ACFT
CTC COMD POST 20 MIN PRIOR TO ARR.
- SEE FLIP AP/1 SUPPLEMENTARY
ARPT RMK.
- CAUTION: EXTV TURBO-PROP
TRNG 1300-0600Z++ MON-FRI.
- BEARING STRENGTH RWY
07-25: ST175 SBTT570 TRT485.
- SERVICE-LGT: SFL INTS
UNCTL MAY BE TURNED OFF O/R.
- SERVICE-LGT: PAPI RWY
07-25 RRP AND PAR/ILS/MLS RPI NOT COINCIDENTAL.
- JASU: 5(A/M 32A-86).
- FUEL: J8-MIN POL CAPABILITY
2200-0600Z++ MON-FRI, EXP 2-4 HR DELAY DUR LCL FLYING.
- FLUID: SP PRESAIR LHOX
LOX.
- OIL: O-133-148-156.
- TRAN ALERT: SVC AVBL
1300-0200Z++ WKD, 1500-2300Z++ SAT, SUN, CLSD HOL. ACFT ARR AFTER 0100Z++ SVC NEXT
DAY.
- RSTD: RWY 069-249 MRK
FOR C130 ASSAULT OPR; USE OF ASSAULT STRIP LDG ZONE RQR PRIOR COORD
WITH 314 AW CURRENT OPS OR COMD POST.
- BEARING STRENGTH RWY 069-249: ST175.
- CAUTION: COMPASS ROSE/SECD
HOT CARGO TWY RSTD TO DAY VFR OPR ONLY, EXC NVG OPR.
- CAUTION: TWY EDGE LGTS
ON TWY C LCTD 26' FR EDGE OF FULL STRENGTH PAVEMENT.
- CAUTION: RWY 25 CNTRLN
MARKINGS OBSCURED BY RUBBER DEPOSITS.
- CAUTION: EXCESSIVE TRANSVERSE
GRADE (19-25%) IS LCTD 100' FR BOTH SIDES OF RWY 07/25 CNTRLN BTN TWYS
CHARLIE & DELTA.
AIRCREWS SHOULD USE EXTREME CAUTION IN THIS AREA.
- SERVICE-LGT: NSTD INFRA-RED
LGT CO-LCTD WITH RWY 25 AND 249 EDGE LGT AND ONE NSTD INFRA-RED STROBE
LCTD END OF RWY 25 AND 249 OVRN. THESE
LGT ARE VIS ONLY THRU NGT NVD.
- RSTD: DEP ACFT REMAIN
AT OR BLW 1300' TIL DEP END OF RWY. FTR ACFT UNABLE TO CTC DEP TIL AIRBORNE.
- CAUTION: PHASE II IN
EFF APR-MAY & SEP-NOV.
- RSTD: NO PRACTICE APCH
OR LDG DUR LCL FLYING.
- NS ABTMT - DEP HVY ACFT
CLIMB RWY HDG TO 1500' AGL PRIOR TO TURNING ON CRS.
- CAUTION: SIGNIFICANT
INCREASE IN BIRD ACT MAR-MAY, AUG-OCT.
- CAUTION: DEER HAZ.
LITTLE ROCK AFB Airport
Address:
Pulaski County, AR
Tel: 501-988-3131
Images and information placed
above are from
http://www.airport-data.com/airport/LRF/
We
thank them for the data!
|
General Info |
| Country |
United
States |
| State |
ARKANSAS
|
| FAA
ID |
LRF
|
| Latitude |
34-54-59.319N
|
| Longitude |
092-08-46.530W
|
| Elevation |
311
feet |
| Near
City |
JACKSONVILLE
|
Thanks to: www.worldaerodata.com
We don't guarantee the information is fresh and accurate. The data may be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
