Ben Gurion International Airport

Ben Gurion International Airport Ben Gurion International Airport is the main aviation gateway of the State of Israel. The Airport serves the majority of passengers flying into and out of Israel.

The Airports Authority, which operates all Airports in Israel, has over recent years been contending with a constant increase in the number of passengers flying into Israel.

The Authority provided a quick fix to the problem of the increasing load at BGN, by adding grounds to the airport compound and installing technological systems, to temporarily increase the capacity of the Airport and improve service to the passenger.

And yet this was insufficient. The basic and ideal solution to the problem of capacity and service levels at the Airport is to be found in the overall plan to expand the existing airport, by establishing a new and modern passenger terminal, Terminal 3.

This will provide a solution to the growing number of passengers passing though the Airport each year, thus obtaining maximum benefit from the new terminal, that will serve tourism, industry and agricultural export.

History:

The first landing strips in the land of Israel were built by the Turks during the First World War, in 1917, at Tzemach in the north, at Ramle in the center and at Gaza in the south, to serve the bi plane fighter aircraft put at their disposal by the Germans.

The 30's
Since its establishment and to the present day, the airport has served as the main entrance and exit gateway for both the citizens and guests of the State of Israel.

The 40's
At the end of the war, civilian activities at the airport slowly returned to full volume and reached a peak.

The 50's
In 1950, Arkia airlines commenced operating internal flights from Lod to Eilat, Mahanayim and Haifa.

The 60's
Regular jet aircraft flights were inaugurated in April 1960, with BEA flights from London and Athens.

The 70's
The first Jumbo landed at the airport already in 1970.

The 80's
During the 80s, passenger traffic at the airport increased, the terminal building was expanded, a new control tower was built and the communications and RADAR installations were improved.

The 90's
At the beginning of the 90s, the airport witnessed the huge wave of immigration that arrived from the Soviet Union.

Information:

Country Code: +972 ~ IDD Access Code: 00 ~ Domestic Prefix: 0 ~ Time Zone: GMT+2
Tel Aviv-Ben Gurion Airport (TLV/LLBG)

SITA: TLVVVLY
Managing Director: Shaul Hazan
Airport Data: 24 hours, 1 Cargo Terminal

Airfield Data: 3 Runways
Runway 1: Heading 03/21, 1,900m (6,233ft), Aircraft size max: B747-400
Runway 2: Heading 8/26, 3,660m (12,007ft)
Runway 3: Heading 12/30, 3,110m (10,203ft)

Cargo Facilities: 4x 747 Freighter Docks, Bonded Warehouse, Transit Zone, Mechanical Handling, Air-Conditioned Storage, Refrigerated Storage, Deep Freeze Storage, Animal Quarantine, Health Officials, X-Ray Equipment, Decompression Chamber, Security for Valuables, Dangerous Goods, Radioactive Goods, Very Large/Heavy Cargo, Express/Courier Centre
Customs Tel: +972 (0)3 971 5511
Op. Hours: 24 hours
Customs Chief: Mr Talit

Passenger Facilities: Annual Capacity 10,000,000

Address:

Tel Aviv, Ben Gurion, Israel,
PO Box 41,
Ben Gurion International Airport,
70100 Lod

Tel: +972 (0)3 971 6111
Fax: +972 (0)3 971 7523

Website: www.iaa gov il/Rashat/en-US/Airports/BenGurion

E-mail: telmas at iaa gov il
E-mail: avia at iaa gov il




Images and information placed above are from
www.iaa gov il/Rashat/en-US/Airports/BenGurion
http://www.azworldairports.com/cfm/frame.cfm?src=http://www.azworldairports.com/airports/p1800.htm

We thank them for the data!


General Info
Country Israel
ICAO ID LLBG
Time UTC+2(+3DT)
Latitude 32.009500
32° 00' 34.20" N
Longitude 34.876897
034° 52' 36.83" E
Elevation 135 feet
41 meters
Type Civil
Magnetic Variation 003° E (01/05)
Beacon Yes
Operating Agency CIVIL GOVERNMENT, (LANDING FEES AND DIPLOMATIC CLEARANCE MAY BE REQUIRED)
Near City Tel Aviv
Operating Hours 24 HOUR OPERATIONS
International Clearance Status Airport of Entry


Communications
TWR 118.3
TMA 119.5
VOLMET 126.8
GND EAST 129.2
CLNC DEL 119.35
ATIS 132.5
APP 120.5


Runways
ID
Dimensions Surface PCN ILS
03/21 5840 x 148 feet
1780 x 45 meters
ASPHALT 084FBYU NO
08/26 11998 x 148 feet
3657 x 45 meters
ASPHALT 084FBYU YES
12/30 10209 x 148 feet
3112 x 45 meters
ASPHALT 078FCXT YES


Navaids
Type ID Name Channel Freq Distance From Field Bearing From Navaid
VOR-DME BGN BEN GURION 082X 113.5 At Field -
NDB LL TEL AVIV - 331 6.3 NM 116.3


Supplies/Equipment
Fuel Jet A1, without icing nhibitor.

100/130 MIL Spec, low lead, aviation gasoline (BLUE)


Remarks
CSTMS/AG/IMG Avbl 24 hr dly exc on Yom Kippur (Sep or Oct)-USDAO will advs.
FUEL A1 (Air BP/Aviation Svc Ltd; No fone listed. (NC-100LL)
LGT PAPI Rwy 08, 12, 26, 30 lt and rgt side.
NS ABTMT Arpt clsd for tkof 0000-0350Z++ due to NS ABTMT exc (1) Medical assistance and relief flt (2) IS Air Force flts (3) Other flts apv by CAA and/or Ben Gurion arptduty mgr. For addn info see FLIP AP/2, Supplementary Arpt Rmk.
RSTD Rpt LDA Rwy 30 is 9664'.

Runway 03/21

5840 x 148 feet
1780 x 45 meters

Runway 03
Surface ASPHALT
True Heading 029.0
Latitude 32.003114
32° 00' 11.21" N
Longitude 34.890842
034° 53' 27.03" E
Elevation 129.0 feet
39 meters
Slope 0.1°
Landing Distance 5840 feet
1780 meters
Takeoff Distance 6056 feet
1846 meters
Overrun Length 216 feet
66 meters
Overrun Surface MACADAM - CRUSHED ROCK WATER BOUND.
Lighting System CL
HIRL

Runway 21
Surface ASPHALT
True Heading 209.0
Latitude 32.017011
32° 01' 01.24" N
Longitude 34.899883
034° 53' 59.58" E
Elevation 134.0 feet
41 meters
Slope -0.1°
Landing Distance 5840 feet
1780 meters
Takeoff Distance 6056 feet
1846 meters
Overrun Length 216 feet
66 meters
Overrun Surface MACADAM - CRUSHED ROCK WATER BOUND.
Lighting System CL
HIRL
PAPI

Runway 08/26

11998 x 148 feet
3657 x 45 meters

Runway 08
Surface ASPHALT
True Heading 080.0
Latitude 32.011978
32° 00' 43.12" N
Longitude 34.860058
034° 51' 36.21" E
Elevation 97.0 feet
30 meters
Slope 0.3°
Landing Distance 11998 feet
3657 meters
Takeoff Distance 12203 feet
3719 meters
Overrun Length 205 feet
62 meters
Overrun Surface MACADAM - CRUSHED ROCK WATER BOUND.
Lighting System CL
HIRL
PAPI

Runway 26
Surface ASPHALT
True Heading 260.0
Latitude 32.017850
32° 01' 04.26" N
Longitude 34.898275
034° 53' 53.79" E
Elevation 135.0 feet
41 meters
Slope -0.3°
Landing Distance 10029 feet
3057 meters
Takeoff Distance 12293 feet
3747 meters
Displaced Threshold Length 1969 feet
600 meters
Overrun Length 295 feet
90 meters
Overrun Surface MACADAM - CRUSHED ROCK WATER BOUND.
Lighting System SF
TDZL
CL
HIRL
REIL
A1
PAPI

Runway 12/30

10209 x 148 feet
3112 x 45 meters

Runway 12
Surface ASPHALT
True Heading 121.0
Latitude 32.013631
32° 00' 49.07" N
Longitude 34.865519
034° 51' 55.87" E
Elevation 102.0 feet
31 meters
Slope 0.3°
Landing Distance 10209 feet
3112 meters
Takeoff Distance 10556 feet
3217 meters
Overrun Length 347 feet
106 meters
Overrun Surface ASPHALT
Lighting System SF
TDZL
CL
HIRL
A1
PAPI

Runway 30
Surface ASPHALT
True Heading 301.0
Latitude 31.998892
31° 59' 56.01" N
Longitude 34.893828
034° 53' 37.78" E
Elevation 130.0 feet
40 meters
Slope -0.3°
Landing Distance 9963 feet
3037 meters
Takeoff Distance 10537 feet
3212 meters
Displaced Threshold Length 246 feet
75 meters
Overrun Length 328 feet
100 meters
Overrun Surface ASPHALT
Lighting System CL
HIRL
REIL
A3
PAPI

Navaids

BEN GURION
Type ID Channel Freq Country State
VOR-DME BGN 082X 113.5 Israel -
Latitude Longitude Airport
32.013111
32° 00' 47.20" N
34.875231
034° 52' 30.83" E
LLBG

Navaids

TEL AVIV
Type ID Channel Freq Country State
NDB LL - 331 Israel -
Latitude Longitude Airport
32.062000
32° 03' 43.20" N
34.770228
034° 46' 12.82" E
LLBG




Thanks to: www.worldaerodata.com

The content above was published at Airports-Worldwide.com in 2005.
We don't guarantee the information is fresh and accurate. The data may be wrong or outdated.
For more up-to-date information please refer to other sources.
